| Max. Print area |
510 mm. |
| Unwind Max. Dia. |
400 mm. |
| Rewind Max. Dia. |
400 mm. |
| Substrates to be print |
Polyester,Bopp, etc. |
| Thickness of substrate |
16 micron to 150 micron |
| Speed Max. (with using Du Pont Sleeves) |
35 - 45 Mtrs / min |
| Unwind / Rewind Core dia. |
76mm / 3" |
| Heater |
4 kW x 1 nos. (415vac) |
| AC Drive |
3 Hp /1.5 kW & 1 Hp (1 no's each) |
| AC Motor |
2 Hp /1.5 kW geared Motor & 1 Hp / 0.75kW Geared Motor / (1 no's each) |
| winding Tension |
AUTO TENSION Control System with Magnetic Clutch. (Make E+L,Etc) |
| Unwinding Roll |
AUTO TENSION Control System with Magnetic brake. (Make E+L,Etc). |
| Counting System |
By using PLC (having both option of SHEET/METER counting). |
| Control System |
By using user friendly TOUCH Panel with PLC control. |
| Web Guiding System |
Web-Edge Guiding System (Make E+L,Etc). |
| Embossing Pressure Digital |
Embossing Pressure is digitally controlled. |
| Panel Margin Adjustment |
Motorized with fine adjustment. |
| Air Requirements |
6-8 Bar |
| Power Requirements |
415V AC 3 phase (7.50 kW) |
| Machine Dimensions (LxWxH) |
(") these dimensions are in INCHES. |
| Machine Weight (Kg) |
|
