| Web Width |
1000 mm/40" |
| Unwind Max. Dia. |
1000 mm/40" |
| Rewind Max. Dia. |
500 mm |
| Min. Slitting Width |
|
| Min Material thickness : |
|
| Rewinding System |
Differential Technology With Ball Type Quick Locks |
| Speed |
370 Mtrs 1 Min. |
| Unwind Core Dia. |
3" (6" optional) |
| Rewind Core Dia. |
3" |
| Ac Drive Main |
7.5hp / 5.5kW (Make Control Technics) |
| Ac Drive Rewind |
5hp / 3.75kW x 2 nos (Make Control Technics) |
| Waste Trim Blower |
1 hp / 0.75kW |
| Free margin Control |
By using web Edge Guide System / web Line Guide System (Make E+L/BST) (Extra chargeable) |
| Touch Screen Interface for easy Operations |
|
| Touch Screen and PLC by Allen Bradley |
|
| Unwind Tension Control |
Automatic Tension Control Throughout Varying Diameter with Pn |
| Rewind Tension Control |
Automatic Tension Control Throughout Varying Diameter with Pneumatic Brakes |
| Air Requirements |
6-8 Bars |
| Power Requirements |
415Vac 3-Phase ( 13.75kW ) |
| Weight |
Approx 1900 kgs |
| Machine Dimensions (in Inch) |
102 (L) x 67 (W) x 65 (H) |
