| Max Web Width |
320 mm |
| Unwind Max. Dia. |
500 mm |
| Rewind Max. Dia. |
500 mm |
| Pneumatic Unwinder, Shaft with 3" dia. |
|
| Pneumatic Rewinder, 2 shafts with 3" dia. |
|
| Upgraded air shafts at unwinder |
rewinder with centralized air supply mechanism which requires no air gun |
| Web Aligning system by E+L (Germany) |
|
| Single Die Cutting Station |
|
| Min/Max Repeat Length per Teeth |
60T-160T |
| Max Die-Cutting Speed |
60M/ Min |
| Waste Rewind |
|
| Max Slitting Speed |
70M/ Min |
| Min Slitting Width |
25 mm |
| Max Slitting Width |
300mm |
| Slitting accuracy |
+/- 0.10 mm |
| Waste Suction blower |
|
| 4 Sets (Upper & Lower Knives Set) Movable Rotary Slitting Cutters for Slitting |
|
| Allen Bradley Make Ac Drive for Speed Control |
|
| Rotational Panel for easy operation in Desired position/direction |
|
| Pre-set Label Counting by using Label Sensor |
Length counter with setting of auto stop when the count is reached |
| Tension Controlled By using Pneumatic Brake on UNWIND & Pneumatic CLUTCH on Rewind. |
|
| Pneumatic Air supply needed 6 Bar |
|
| Power |
Approx 2.0 kw,415V, 50Hz, 3 Phase |
| Dimensions (in mm) |
61 (L) x 41 (W) x 59 (H) |
| Weight |
Approx 700 kgs |
